MC9S08QE8CLC 8-bit Microcontroller - MCU 8 BIT 8K FLASH NXP / Freescale
Art. #: 230MC9S08QE8CLC
Disponibilità:
disponibile
| Quantità | Prezzo | IVA esclusa | IVA inclusa* |
|---|---|---|---|
| 1 | Listino | 6,00 € | 7,32 € |
| 10 | 5% | 5,70 € | 6,954 € |
| 25 | 10% | 5,40 € | 6,588 € |
| 50 | 20% | 4,80 € | 5,856 € |
* In fase di conferma d'ordine, i prezzi IVA inclusa verranno arrotondati alla seconda cifra decimale in accordo alla normativa vigente
MC9S08QE8CLC
The MC9S08QE8CLC is a 8-bit Microcontroller based on enhanced HCS08 CPU (10MHz bus) with CISC architecture operates at a maximum frequency of 20MHz. The device incorporates 8kB internal flash, 0.512kB internal RAM, 10-channel 12-bit A/D converter and 26 general-purpose I/O pins. This device also features peripherals like one inter-integrated circuit (IIC) bus module to operate at up to 100kbps, one serial peripheral interface modules (SPI) and an analog comparator. Internal clock source (ICS) containing a frequency-locked-loop (FLL) controlled by internal or external reference, precision trimming of internal reference allowing 0.2% resolution and 2% deviation. Watchdog computer operating properly (COP) reset with option to run from dedicated 1kHz internal clock source.
- Product Category: 8-bit Microcontrollers - MCU
- RoHS: Details
- Series: S08QE
- Mounting Style: SMD/SMT
- Package/Case: LQFP-32
- Core: S08
- Program Memory Size: 8 kB
- Data Bus Width: 8 bit
- ADC Resolution: 12 bit
- Maximum Clock Frequency: 20 MHz
- Number of I/Os: 26 I/O
- Data RAM Size: 512 B
- Supply Voltage - Min: 1.8 V
- Supply Voltage - Max: 3.6 V
- Minimum Operating Temperature: - 40 C
- Maximum Operating Temperature: + 85 C
- Interface Type: I2C, SCI, SPI
- Number of ADC Channels: 10 Channel
- Number of Timers/Counters: 2 Timer
- Processor Series: MC9S08
- Product: MCU
- Product Type: 8-bit Microcontrollers - MCU
- Program Memory Type: Flash
Codici prodotto: 075702, MC9S08QE8CLC
