Brand:
Finder
Rele_Fi..022.pdf
(215.44 KB)
Finder 30.22.7.005.0000 Mini Relay Dual in Line Coil Sensitive 5 VDC
Product Code: 28130227005
Inventory Status:
in stock
| Quantity | Price | VAT excluded | VAT included |
|---|---|---|---|
| 1 | Default | €5.632 | €6.87104 |
| 1 | Promo | €4.7872 | €5.840384 |
* During the order confirmation phase, the prices including VAT will be rounded to the second decimal place according to with current legislation
DIL Dual in Line subminiature relay, 2 changeover 2A, with 200mW 5 VDC coil
Finder 30.22.7.005 | |
30 | Series 30 |
2 | Printed circuit |
2 | Two contacts, 2 A |
7 | Sensitive DC coil |
005 | Coil nominal voltage |
Contact characteristics
- Contact configuration: 2 exchanges
- Rated current / Max instantaneous current: 2A / 3A
- Rated voltage / Max switching voltage: 125 VAC / 250 VAC
- Rated load in AC1: 125 VA
- Rated load in AC15 (230 V AC): 25 VA
- Single-phase motor capacity (230 V AC): -
- Breaking capacity in DC1: 30/110/220: 2 / 0.3 / - VA
- Minimum switchable load: 10mW (0.1 / 1V / mA)
- Standard contact material: AgNi + Au
Characteristics of the coil
- Nominal supply voltage (UN): 5 VDC
- Rated power: 0.2W
- Operating range: 3.7 ÷ 7.5 V
- Holding voltage: 0.35 A
- Release voltage: 0.05 A
General characteristics
- Mechanical life: 1 million cyclesi
- Electrical durability at nominal load in AC1: 100,000 cycles
- Tripping time: on / off: 6 ms / 2 ms
- Insulation between coil and contacts (1.2 / 50 µs): 1.5 kV (8mm)
- Dielectric strength between open contacts: 750 VAC
- Ambient temperature: –40… + 85 ° C
- Protection category: RT III
Dimensions
 |
Product Codes: 30.22.7.005.0000, 302270050000
